Model Range (kW): 6, 8, 10, 12, 14, 16 (single-phase 220–240 V) & 12, 14, 16 (three-phase 380–415 V).
Refrigerant: R32, 33 % lower GWP than R410A, fully factory-charged (1.25–1.80 kg).
Compressor: GMCC twin-rotary DC inverter for smooth modulation and reduced inrush currents.
Fans: Large axial fans (Φ580×190 mm) driven by brushless DC motors for quiet, efficient airflow; sound levels 60–67 dB(A).
Heat Exchangers: Hydrophilic-coated aluminum fins over inner-grooved copper tubes (air-side); stainless steel plate-type (water-side).
Controls: Electronic expansion valve, water-flow switch, pressure sensors, and integrated expansion vessel for stable hydronic operation.
Dimensions: 1 040×850×450 mm (packaged 1 150×983×527 mm); weight 75–88 kg net.
Installation: “Water-pipe only” with G5/4″ BSP connections; no field refrigerant work required.
Operating Envelope: Cooling ambient 18 °C–56 °C; heating ambient –25 °C–35 °C; water setpoints 5 °C–25 °C (cooling), 25 °C–60 °C (heating).
COP up to 4.90 at A35/W18, outperforming many R32 mini chillers.
Operates reliably at ambient air temperatures up to 56 °C and down to –25 °C, ideal for T3 zones.
Fits small mechanical rooms or outdoor patios; quick “water-pipe only” hookup saves installation time.
DC inverter compressors and fans continuously modulate to match load, reducing start/stop losses by up to 30 %.
R32 refrigerant reduces CO₂ equivalent emissions; meets global HFC phase-down regulations.
Tropical Residences: Villas and apartments in T3 zones seeking efficient AC and DHW support.
Light Commercial: Boutique hotels, cafes, and guesthouses requiring compact chillers.
Retrofit Projects: Replace outdated split-system chillers with a single-module chiller.
Energy-Smart Homes: Smart BMS integration for load-shedding and peak-shaving strategies.
Certifications: CE, RoHS, global HFC phase-down compliance.
Testing Standards: EN14511 (EER/COP), EN14825 (seasonal efficiency), tropical climate testing per AHRI 540.
Warranty: 2 years parts & labor; extended options available.
Service Network: Authorized installers and rapid spare-parts distribution in T3 regions.
| Model | 6kW | 8kW | 10kW | 12kW | 14kW | 16kW | ||
| Power supply(V/Ph/Hz) | 220-240V/1PH / 50HZ | |||||||
| Cooling A35W18 | Capacity | W | 6613 | 8400 | 10000 | 12500 | 14000 | 15000 |
| Rated input | W | 1349 | 1806 | 2326 | 2907 | 3390 | 3886 | |
| COP | 4.900 | 4.650 | 4.300 | 4.300 | 4.130 | 3.860 | ||
| Cooling A35W7 | Capacity | W | 5757 | 7500 | 9000 | 11800 | 12500 | 13200 |
| Rated input | W | 1904 | 2419 | 3103 | 4069 | 4386 | 4800 | |
| COP | 3.020 | 3.100 | 2.760 | 2.900 | 2.850 | 2.750 | ||
| Sound power level2 | Cooling A35W18 | dB | 60 | 63 | 63 | 65 | 66 | 67 |
| Compressor | Type | DC inverter, twin-rotary | ||||||
| Brand | GMCC | GMCC | GMCC | GMCC | GMCC | GMCC | ||
| Quantity | 1 | 1 | 1 | 1 | 1 | 1 | ||
| Motor | Rated input | W | 170 | 170 | 170 | 170 | 170 | 170 |
| Type | Brushless DC | Brushless DC | Brushless DC | Brushless DC | Brushless DC | Brushless DC | ||
| Brand | LT | LT | LT | LT | LT | LT | ||
| Quantity | 1 | 1 | 1 | 1 | 1 | 1 | ||
| Fan | Type | Axial | Axial | Axial | Axial | Axial | Axial | |
| Fan size (ΦD×H) | mm | Φ580×190 | Φ580×190 | Φ580×190 | Φ580×190 | Φ580×190 | Φ580×190 | |
| Air side heat exchanger | Type | Hydrophilic aluminum & Inner groove copper tube | ||||||
| Rows | 1.6 | 1.6 | 1.6 | 3 | 3 | 3 | ||
| Tube diameter | mm | Φ7 | Φ7 | Φ7 | Φ7 | Φ7 | Φ7 | |
| Fin space | mm | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | |
| Refrigerant | Type | R32 | R32 | R32 | R32 | R32 | R32 | |
| Factory charged | kg | 1.25 | 1.25 | 1.25 | 1.80 | 1.80 | 1.80 | |
| Throttle | Type | Electronic expansion valve | ||||||
| Water side heat exchanger | Type | Plate | Plate | Plate | Plate | Plate | Plate | |
| Expansion vessel | Volume | L | 5 | 5 | 5 | 5 | 5 | 5 |
| Max. working pressure | MPa | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | |
| Safety valve | MPa | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | |
| Water flow switch | m3/h | 0.36 | 0.36 | 0.36 | 0.36 | 0.36 | 0.36 | |
| Inlet/outlet water pipes size | G5/4″BSP | G5/4″BSP | G5/4″BSP | G5/4″BSP | G5/4″BSP | G5/4″BSP | ||
| Unit dimension (W×H×D) | mm | 1040*850*450 | ||||||
| Packing dimension (W×H×D) | mm | 1150*983*527 | ||||||
| Outdoor net weight | kg | 75 | 75 | 75 | 88 | 88 | 88 | |
| Outdoor gross weight | kg | 91 | 91 | 91 | 104 | 104 | 104 | |
| Ambient temperature range | Cooling | ºC | 18～56 | 18～56 | 18～56 | 18～56 | 18～56 | 18～56 |
| Heating | ºC | -25～35 | -25～35 | -25～35 | -25～35 | -25～35 | -25～35 | |
| Water setting temperature range | Cooling | ºC | 5~25 | 5~25 | 5~25 | 5~25 | 5~25 | 5~25 |
| Heating | ºC | 25~60 | 25~60 | 25~60 | 25~60 | 25~60 | 25~60 | |
| Model | 12kW | 14kW | 16kW | ||
| Power supply(V/Ph/Hz) | 380-415V/3PH / 50HZ | ||||
| Cooling A35W18 | Capacity | W | 12500 | 14000 | 15000 |
| Rated input | W | 2907 | 3390 | 3886 | |
| COP | 4.300 | 4.130 | 3.860 | ||
| Cooling A35W7 | Capacity | W | 11800 | 12500 | 13200 |
| Rated input | W | 4069 | 4386 | 4800 | |
| COP | 2.900 | 2.850 | 2.750 | ||
| Sound power level2 | Cooling A35W18 | dB | 65 | 66 | 67 |
| Compressor | Type | DC inverter, twin-rotary | |||
| Brand | GMCC | GMCC | GMCC | ||
| Quantity | 1 | 1 | 1 | ||
| Motor | Rated input | W | 170 | 170 | 170 |
| Type | Brushless DC | Brushless DC | Brushless DC | ||
| Brand | LT | LT | LT | ||
| Quantity | 1 | 1 | 1 | ||
| Fan | Type | Axial | Axial | Axial | |
| Fan size (ΦD×H) | mm | Φ580×190 | Φ580×190 | Φ580×190 | |
| Air side heat exchanger | Type | Hydrophilic aluminum & Inner groove copper tube | |||
| Rows | 3 | 3 | 3 | ||
| Tube diameter | mm | Φ7 | Φ7 | Φ7 | |
| Fin space | mm | 1.5 | 1.5 | 1.5 | |
| Refrigerant | Type | R32 | R32 | R32 | |
| Factory charged | kg | 1.80 | 1.80 | 1.80 | |
| Throttle | Type | Electronic expansion valve | |||
| Water side heat exchanger | Type | Plate | Plate | Plate | |
| Expansion vessel | Volume | L | 5 | 5 | 5 |
| Max. working pressure | MPa | 0.8 | 0.8 | 0.8 | |
| Safety valve | MPa | 0.3 | 0.3 | 0.3 | |
| Water flow switch | m3/h | 0.36 | 0.36 | 0.36 | |
| Inlet/outlet water pipes size | G5/4″BSP | G5/4″BSP | G5/4″BSP | ||
| Unit dimension (W×H×D) | mm | 1040*850*450 | |||
| Packing dimension (W×H×D) | mm | 1150*983*527 | |||
| Outdoor net weight | kg | 88 | 88 | 88 | |
| Outdoor gross weight | kg | 104 | 104 | 104 | |
| Ambient temperature range | Cooling | ºC | 18～56 | 18～56 | 18～56 |
| Heating | ºC | -25～35 | -25～35 | -25～35 | |
| Water setting temperature range | Cooling | ºC | 5~25 | 5~25 | 5~25 |
| Heating | ºC | 25~60 | 25~60 | 25~60 | |
| Note: 1. The above data test reference standard EN14511; EN14825; EN50564; EN12102; (EU) No:811/2013; (EU)No:813/2013; OJ 2014/C 207/02. 2. Sound power test condition：EN12102-1 |
